Studica Robotics
Build Better Robots®
Studica Robotics is an affordable building system platform that offers everything you need to create sturdy robots of your own design! Our wide selection offers hundreds of parts and robotics kits which are ideal for use in Higher Education and K12 classrooms, with robotics teams, homeschoolers, hobbyists for prototyping robots, industry, and anyone who loves making robots. With a variety of structure and motion components, electronics, hardware, and building kits, you'll find everything you need to make your robotic build ideas come to life.
Why Choose the Studica Robotics Building System?
High Schools and Middle Schools (7th and 8th grades) can incorporate the hands-on learning tools into their STEM curriculum to teach math, physics and computer science. College and University robotics and computer science programs can use the platform to learn about control systems, sensors, programming and concepts related to artificial intelligence. All components work easily together - no need for a machine shop or special equipment. There are many unique advantages to this cutting edge building platform, including;
- VMX Robotics Controller is the heart of an intelligent robot and includes software libraries, example code and many more features. It can be programmed with Java, C++, Python, and ROS. The VMX offers a multitude of modern digital
communications interfaces and with a Linux-based operating system, users can directly access most modern devices like Intel RealSense tracking, LIDAR, and depth cameras. - Titan Quad Motor Controller is a powerful, 4-channel CAN-based motor controller with a built-in fuse-box (for DC motors up to 20A). Features 4 hardware encoder ports, 2 power extension ports to power other 12VDC devices, a built in
LED controller, and more. - Structural Elements - The 3mm thick 6061-T6 aluminum structure is deburred, polished and blue anodized, making your robot or automation project strong, safe and stand out against the rest. The unique design pattern makes it easy to connect the structure, sprockets, motors, and gears. A large center hole makes it possible to integrate flange bearings to provide the ultimate support of shafts and motors. There are also a large variety of beams, flats, and brackets to allow you to build at multiple angles for unique chassis and mechanism. A multitude of mounting options for servos and DC motors mounts are available as well as gears, sprockets, pulleys, and chain.
- Motion Components - The Multi-Mode Smart Servo features an ultra-stout steel gear train to provide more torque. This angular programmable servo can fill a variety of roles on your robot or project. In the default mode, the servo can rotate 300 degrees while having positioning feedback. In this mode, the PWM signal will determine the position of the servo. Using the Smart Robot Servo Programmer (sold separately) the Multi-Mode Smart Servo can be configured to run in continuous, standard, and custom angular mode. A Maverick DC Gear Motor and a variety of wheel options are also available.
Resources
- Studica Robotics - 3D CAD files - For anyone designing their robot or automation system using our Studica Robotics Building Set, you can find all the 3D .STP Files here (Patented). You can use solid modelling software such as PTC Onshape, Solidworks, and Fusion 360 to open and work with these files.
- Training Videos - You can find training videos on the Studica Robotics products.
Studica Robotics is a Global Partner and official exclusive product supplier for the WorldSkills Autonomous Mobile Robotics Competition for Lyon 2024 & Shanghai 2026 and is used in over 40 countries around the world. View Usage Map.
ATTN: FIRST Teams - Studica Robotics is compatible with most FRC and FTC systems allowing you to combine structural components and electronics. You may be eligible for special pricing on robotics kits and parts. Submit this application form to find out. Also, check out our YouTube page to see Studica Robotics in action. If you need help, contact us.
Servo Mount Offset Plate
The Servo Mount Offset Plate is one option to mount the Multi-Mode Smart Servo (75002) to the Studica building structure.
Servo Power Block
The Studica Servo Power Module is a 6V, 60W power injector that enables the use of high-power RC servos. The Servo Power Module passes through input signals unaltered while providing up to 60W of total output power across all eight channels. The input and output channels accept standard 3-wire, 0.1” pitch, servo/PWM cables.
Features,
- Built in DC-DC converter
- Over-current shutdown
- ESD protection
Specifications,
- Nominal Input Voltage: 12V
- Operational Voltage Range: 6.0V
- Number of Channels: 8
- Max Current for All Channels Combined: 10A
- Total Continuous Power: 60W
- Size: 70mm x 45mm x 16mm
- Step File
X Bracket (2 pack)
The X Bracket is perfect for connecting four channels pieces together. Each of the 4 sections is 48mm wide and the overall dimmension is 144mm x 144mm.
Specifications:
- Material - Anodized 6061-T6 Aluminum
- Thickness - 3mm
- Step File
100mm Drive Wheel, 50A, 12.5mm wide, 1/2" Inner Hex, Blue
The 100mm Drive Wheel (4") can be used as a simple wheel providing good traction on carpet and tile flooring. They can also be used for intake systems. Use with 1/2" hex shaft of use 6mm Shaft Hub to use connect 6mm D-Shaft. Axles.
100mm Drive Wheel, 50A, 25mm wide, 1/2" Inner Hex, Blue
The 100mm Drive Wheel (4") can be used as a simple wheel providing good traction on carpet and tile flooring. They can also be used for intake systems. Use with 1/2" hex shaft of use 6mm Shaft Hub to use connect 6mm D-Shaft Axles.
Specifications:
- Diameter: 100mm (4")
- Axial width: 25 mm
- Hub: 1/2" Inner Hex
- Inner Material: Molded Plastic in Yellow
- Outer Material: TPU Polyurethane in Blue
- Outer Material Durometer: 50A
- Weight: 0.068kg
100mm Flex Wheel, 35A, 25mm wide, 1/2" Inner Hex, Green
The 100mm (4") Flex Wheel can be used for intake systems and conveyors.
Specifications:
- Diameter: 100mm (4")
- Axial width: 25mm
- Hub: 1/2" Inner Hex
- Inner Material: Molded Plastic in Yellow
- Outer Material: TPU Polyurethane in Green
- Outer Material Durometer: 35A
- Weight: 0.038kg
100mm Flex Wheel, 40A, 25mm wide, 1/2" Inner Hex, Orange
The 100mm (4") Flex Wheel can be used for intake systems and conveyors.
Specifications:
- Diameter: 100mm (4")
- Axial width: 25mm
- Hub: 1/2" Inner Hex
- Inner Material: Molded Plastic in Yellow
- Outer Material: TPU Polyurethane in Orange
- Outer Material Durometer: 40A
- Weight: 0.038kg
- Step File
192mm x 96mm Flat Bracket (2 pack)
The Studica 192mm x 96mm Flat Bracket is a very strong 3mm. As with the other Studica Robotics building components, it has the common hole pattern which makes it easy to connect to other structure with very little or no additional machining required. You can easily connect to other channel, extrusions, bushings, bearing, mounting brackets and more so you can quickly assemble and disassemble robots and automated systems.
Specifications:
- Material - Anodized 6061-T6 Aluminum
- Thickness - 3mm
- Width - 96mm
- Length - 192mm
- Step File
384mm Low Profile U-Channel
The Studica Low Profile U Channel is 3mm thick and has a 48mm x 14mm profile. As with the other Studica Robotics building components, it has the common hole pattern which makes it easy to connect to other structure with very little or no additional machining required. You can easily connect to other channel, extrusions, bushings, bearing, mounting brackets and more so you can quickly assemble and disassemble robots and automated systems.
Specifications:
- Material: 6061-T6 Aluminum
- Thickness - 3mm
- Height - 14mm
- Width - 48mm
- Length - 384mm
- Hole pattern - 8
- Step File
384mm U-Channel
The Studica U Channel is 3mm thick and has a 48mm x 48mm profile. As with the other Studica Robotics building components, it has the common hole pattern which makes it easy to connect to other structure with very little or no additional machining required. You can easily connect to other channel, extrusions, bushings, bearing, mounting brackets and more so you can quickly assemble and disassemble robots and automated systems.
Specifications:
- Material: 6061-T6 Aluminum
- Thickness - 3mm
- Height - 48mm
- Width - 48mm
- Length - 384mm
- Hole pattern- 8
- Step File
432mm Flat Beam
The Studica Flat Beam is 3mm thick and 8mm wide. As with the other Studica Robotics building components, it has the common hole pattern which makes it easy to connect to other structure with very little or no additional machining required. You can easily connect to other channel, extrusions, bushings, bearing, mounting brackets and more so you can quickly assemble and disassemble robots and automated systems. Ideal for rapid prototyping.
Specifications:
- Material: 6061-T6 Aluminum
- Thickness - 3mm
- Width - 8mm
- Length - 432mm
- Step File
48mm L-Beam (2 pack)
The Studica L-Beam is available in 9 different lengths from 48mm to 432mm. It is strong while light weight. It can be easily cut to your own custom size. The hole pattern matches the hole patterns in the Studica U-Channel, Low Profile U-Channel, and the various plates. Ideal for rapid prototyping.
Specifcations,
- Material: 6061-T6 Aluminum
- Length: 48mm
- Width: 14mm
- Height: 14mm
- Thickness: 3mm
- Hole Diameter: 3.5mm
- Weight: 0.009kg
- Step File
48mm Square Beam
The Studica Square Beam is 8mm by 8mm. As with the other Studica Robotics building components, it has the common hole pattern which makes it easy to connect to other structure with very little or no additional machining required. You can easily connect to other channel, extrusions, bushings, bearing, mounting brackets and more so you can quickly assemble and disassemble robots and automated systems. Ideal for rapid prototyping.
Specifications:
- Material - Anodized 6061-T6 Aluminum
- Holes - 3.5mm diameter spaced 8mm apart
- Length - 48mm
- Step File
5mm Thick 3M Screw Spacer (10 pack)
Made from delrin in blue, this M3 Screw Spacer has a 3.2mm ID x 5.5mm OD x 5mm thick. Use it for any M3 screw.
