X Bracket

The Studica Robotics 120 Degree Bracket, available in six different colors, is ideal for connecting two channel pieces at 120 degrees from each other. Each side is 48mm wide to fit perfectly on the channel. Use 3 brackets with 3 channel pieces to make 3 wheeled robots.

Note: Our new colors are now in stock !

The Studica Robotics 135 Degree Bracket, available in six different colors, is ideal for connecting two channels pieces at 45 degrees from each other. Each side is 48mm wide to fit perfectly on the channel.

Note: Our new colors are now in stock !

The Studica Robotics 90 Degree Bracket is ideal for connecting two channel pieces at a 90-degree angle from each other and is part of our colored structure collection.

Each side is 48mm wide to fit perfectly on the channel. As with the other Studica Robotics building components, it has the common hole pattern which makes it easy to connect to other structure with very little or no additional machining required.

Note: Our new color structure components (red, green, blue, silver, gold, and black) are now in stock!

Made from 3mm thick 6061-T6 Aluminum, available in six different colors, the Studica Robotics Inside L Bracket is 42mm x 45mm and is used inside a U-Channel or Low profile channel.  As with the other Studica Robotics building components, it has the common hole pattern which makes it easy to connect to other structure with very little or no additional machining required.

Note: Our new colors are now in stock !

Made from 3mm thick heavy 6061-T6 Aluminum, the Studica Robotics Inside U Bracket (available in six different colors) is 42mm x 45mm and is used inside a U-Channel or Low profile channel. As with the other Studica Robotics building components, it has the common hole pattern which makes it easy to connect to other structure with very little or no additional machining required. You can easily connect to other channel, extrusions, bushings, bearing, mounting brackets and more so you can quickly assemble and disassemble robots and automated systems.

Note: Our new colors are now in stock !

The Studica Robotics L-bracket is made from 3mm thick, 6061-T6 Aluminum, with a length and width of 48mm x 48mm.  The L-bracket is used outside a  U-Channel or Low profile channel.  As with the other Studica Robotics building components, it has the common hole pattern which makes it easy to connect to other structure with very little or no additional machining required. Now available in a variety of colors.

Note: Our new colors are now in stock !

The Studica Robotics T Bracket is ideal for connecting two or three channels together. Each side is 48mm wide to fit on a U-Channel, low profile channel or other brackets. The overall size is 144mm x 96mm.  Now available in six different colors.

Note: Our new colors are now in stock !
