PmodSSD Seven-segment display

FT232R Serial to USB Interface Pmod™ Platform Evaluation Expansion Board

The PmodSWT provides users with four slides switches for up to 16 different binary logic inputs to for the attached system board.

Features:

• 4 slide switches
• Add user input to host board or project
• Static binary logic input
• Small PCB size for flexible designs 1.3 in × 0.8 in (3.3 cm × 2.0 cm)
• 6-pin Pmod connector with GPIO interface
• Follows Digilent Pmod Interface Specification Type 1

PmodKYPD - 16-Button Keypad is a peripheral module featuring a 16-button keypad. The keys are numbered in a hexadecimal fashion (0-9, A-F). It uses a standard 12-pin Pmod header that will indicate which row and which column has been pressed in the array of buttons.
