PmodTMP2 Thermometer/thermostat

The Pmod VGA provides a VGA port to any board with Pmod connectivity. The VGA port can be used to drive standard displays such as televisions and monitors. The host board must be capable of driving a fast parallel data bus in order to properly drive a display with the Pmod VGA.

The PmodACL2 is a 3-axis MEMS accelerometer powered by the Analog Devices ADXL362. By communicating with the chip via the SPI protocol, users may receive up to 12 bits of resolution for each axis of acceleration.

Features:

• Based on the Analog Devices ADXL362 3-Axis MEMS Accelerometer
• Communicates via SPI
• User selectable resolution
• Less than 2 μA of current consumption at 100 Hz output data rate
• Single or double-tap detection capability
• Free-fall detection

The Digilent PmodALS demonstrates light-to-digital sensing through a single ambient light sensor. Digilent Engineers designed this Pmod around Texas Instrument's ADC081S021 analog-to-digital converter and Vishay Semiconductor's TEMT6000X01.

PmodKYPD - 16-Button Keypad is a peripheral module featuring a 16-button keypad. The keys are numbered in a hexadecimal fashion (0-9, A-F). It uses a standard 12-pin Pmod header that will indicate which row and which column has been pressed in the array of buttons.

The PmodMAXSONAR is a single-transducer ultrasonic range finder that uses the MaxBotix® LV-MaxSonar®-EZ1™. Users can measure how far away an object is with an accuracy within 1 inch to over 20 feet away. Information is sent in a variety of ways including UART, PWM, and analog signals.

Features:

• Ultrasonic range finder with effective detection range of 6 in - 255 in (15 cm - 648 cm)
• Detect object distance with 1.0 in (2.54 cm) resolution up to 20 ft away
• Continuous measurement (free run) operation
• Three options for sending range data: UART, analog and PWM
• Small PCB size for flexible designs 0.9 in × 0.8 in (2.3 cm × 2.0 cm)
• 6-pin Pmod connector with UART interface

The PmodSSD is a two-digit seven-segment display. Users can toggle through GPIO signals which digit is currently on at a rate of 50 Hz or greater to achieve persistence-of-vision to give the effect of both digits being lit up simultaneously.

The PmodSWT provides users with four slides switches for up to 16 different binary logic inputs to for the attached system board.

Features:

• 4 slide switches
• Add user input to host board or project
• Static binary logic input
• Small PCB size for flexible designs 1.3 in × 0.8 in (3.3 cm × 2.0 cm)
• 6-pin Pmod connector with GPIO interface
• Follows Digilent Pmod Interface Specification Type 1

FT232R Serial to USB Interface Pmod™ Platform Evaluation Expansion Board
