Makeblock Me PIR Motion Sensor

The Makeblock Me PIR sensors are used to detect motion from animals/ humans from about 6m away. If anything moved in that range, the sensor outputs HIGH on its SIG pin. With a potentiometer soldered on its circuit board, you can adjust its detecting range according to your need. Some great DIY project ideas include: motion detecting, thief-guarding system, automation switch.

MFR Part #: 11010

$8.11

Regular: $8.99

Availability: 1 in stock

Qty:

Overview
Reviews

Key Features:

Adjustable detecting range and high sensity
A power indicator LED(Red) and a state indicator(Blue)
16mm interval M4 mounting holes, compatible with Makeblock beams
2.54mmbreakout pins for connecting with jumper wires
Easy wiring with 6 Pin RJ11 interface
Arduino library for easy programming

Specification:

Rated Voltage: 5V
working temperature:-20℃～＋70℃
Level output voltage: 5V/high, 0V/low
Trigger signal: 5V/high
Holding time: 2s
Detecting angle: 120 degree
Detecting distance: max 6m
Size:24x48x 32mm(Length x Width x Height)
