FTC Power Block

The Studica Robotics XT30 Male to JST-VH cable is used to connect the Servo Power Block (75006) tothe FTC Power ecosystem. The cable can be used to connect the FTC Power block to Servo Power Block and the Servo Power Block to REV Control Hub.

The Studica Robotics Servo Power Block (75006) with the XT30 Male to JST-VH Cable (70180) Bundle is made for FIRST FTC Teams. The Servo Power Block is a 6V, 60W power injector that provides proper power for RC Servos. It does not interfere with the signal, it will only replace the power to the servo with 6V.  The XT30 Male to JST-VH Cable allows you to plug directly into the REV Control Hub.

Note: This servo power block is legal for FIRST (FTC) competitions.

The Servo Power Block is a 6V, 60W power injector that provides proper power for RC Servos. It does not interfere with the signal, it will only replace the power to the servo with 6V.

Note: This servo power block is legal for FIRST (FTC) competitions.

Used with the Intake Kit to create various intake system with various lengths.

The JST-GH to JST-GH Cable connects external sensors, breakout boards or other devices.

Detailed Specifications:

• Cable Length: 25 cm
• Connectors: 4-pin JST-GH (2)
• Wire Colors: Black, Red, Blue, Green

The Studica Robotics Linear Servo RC Actuator 140S-190N is a new linear servo motor which has a stroke of 140mm and a max force of 190N.

Note: This actuator is legal for FIRST (FTC) competitions.

The Studica Robotics Slide Rail is made of 6061 lightweight aluminum, is 24mm wide, and is perfect for linear motion and building a multi-stage slide system. Closed length is 288m, with a 180mm stroke, creating an extended length of 468mm.

The M3 x 10mm low profile screw with Kep Nut is a 304 Stainless Steel M3 Din 7991 countersunk hex socket flat head screw with a matching Kep Nut. This package is made for the Slide Rail, 288mm Length, 180mm Stroke and the Slide Rail, 384mm Length, 240mm Stroke

The Studica Robotics 38mm Omni Wheel was designed as an odometry wheel that can fit inside most channel sizes. For ease of use, three cores were designed to fit the 6mm D-Shaft, 5mm Hex Shaft, and 7mm Hex Shaft. The wheel is open for easy use in any ecosystem with the provided different-sized cores.

The XT30 extension cable is a great solution to add distance to your wiring connections.
