UND Basic Parts Bundle for EE206L (NI myDAQ not included)

NI myDAQ student bundle for University of North Dakota students includes:

• 1 - NI myDAQ with LabVIEW, NI Multisim and NI Ultiboard
• 1 - 350 pc. Pre-formed Jumper Wire Kit
• 1 - myDEV ProtoBoard for NI myDAQ
• 3 - 1k Resistors
• 6 - 510Ω Resistors
• 2 - 1MΩ Resistors
• 3 - Diode Ultra Fast Recovery Rectifier 100 Volt 0.3A 2-Pin DO (1N4148)
• 2 - Transistor General Purpose BJT NPN 40 Volt 0.2 Amp 3-Pin TO-92 (2N3904-R)
• 4 - LED Uni-Color Orange Red 620nm 2-Pin (BVU-5M1QN1)
• 2 - QUAD 2-INPUT POSITIVE NAND GATE DIP-14 (74LS00)
• 3 - QUAD 2-INPUT POSITIVE NOR GATE DIP-14 (74LS02)
• 2 - HEX INVERTER DIP-14 (74LS04)
• 3 - QUAD 2-INPUT POSITIVE AND GATE DIP-14 (74LS08)
• 3 - Triple 3 Input Positive NAND Gate DIP 14 (74LS10)
• 2 - Triple 3 Input Positive AND Gate DIP 14 (74LS11)
• 3 - DUAL 4-INPUT NAND GATE DIP-14 (74LS20)
• 3 - Triple 3 Input NOR Gate DIP 14 (74LS27)
• 3 - QUAD 2-INPUT POSITIVE OR GATE DIP-14 (74LS32)
• 3 - DUAL D-TYPE FLIP-FLOP DIP-14 (74LS74)
• 3 - 4-BIT BINARY FULL ADDER DIP-16 (74LS83)
• 2 - QUAD 2-INPUT EXCLUSIVE OR GATE DIP-14 (74LS86)
• 2 - Asynchronous Decade Counter DIP-14 (74LS90)
• 2 - 3-TO-8 DECODER/DEMULTIPLEXER DIP-16 (74LS138)
• 2 - DUAL 2-TO-4 DECODER/DEMULTIPLEXER DIP-16 (74LS139)
• 2 - 1-TO-8 DATA SELECTOR/MULTIPLEXER DIP-16 (74LS151)
• 2 - DUAL 4-TO-1 DATA SELECTOR/MULTIPLEXER DIP-16 (74LS153)
• 2 - QUAD 2-TO-1 LINE DATA SELECTOR DIP-16 (74LS157)
• 2 - Synchronous 4 Bit Binary Counter DIP-16 (74LS163)
• 3 - 470 Ohm 1/2 Watt 5% (661423)
• 3 - 220 Ohm 1/2 Watt 5% (661343)
• 3 - LED Display 7-Segment Red 0.30 Inch Common Anode LHDP/RHDP 2.5mcd (24740)
• 3 - SN74LS47N - 7447 IC (296-3712-5-ND?)
• 1 - Soldering Kit (AK-100)
• 1 - Alligator Clips
• 1 - LED Green Light
• 1 - LED Red/Orange Light
• 1 - 2390 Tie Point Breadboard with Jumper Wire Kit

• 1 - 9V battery
• 1 - Thermistor 10k
• 5 - LED indicators - Red
• 2 - 1.5MHZ 8DIP Op-Amps
• 2 - 1kΩ Resistors
• 2 - 4.7kΩ Resistors
• 2 - 3.3kΩ Resistors
• 2 - 2.2kΩ Resistors
• 2 - 15kΩ Resistors
• 3 - 7.5kΩ Resistors
• 1 - Thermistor PTC 100 Ohm 2 Pin
• 1 - Thermistor NTC K +/-10% 100k Ohm
• 1 - 1/2" Circular Force Sensing Resistor
• 1 - 1.5 To 24 Volt Motor Grab Bag

(Does Not Include the myDAQ/Protoboard)

The myDevBoard is an accessory board designed to connect directly to the NI myDAQ hardware. The Protoboard consists of a prototyping space as well as each I/O line from NI myDAQ broken out through quad contact blocks to make wiring easier.

This student bundle for University of North Dakota - EE313L, includes:

• 1 - 10K OHM 5% 1/4W AXIAL Resistor
• 1 - 1K OHM 5% 1/6W AXIAL Resistor
• 1 - 100 OHM 5% 1/4W AXIAL Resistor
• 1 - 120 OHM 5% 1/4W AXIAL Resistor
• 1 - 200 OHM 5% 1/6W AXIAL Resistor
• 1 - 5 OHM 5% 5W AXIAL Resistor
• 1 - 16K OHM 5% 1/4W AXIAL Resistor
• 1 - CER 1UF 25V X7R RADIAL Capacitor
• 1 - FIXED IND 10MH 170MA 10.86OHM TH
• 1 - FIXED IND 1MH 100MA 20 OHM TH
• 1 - SWITCH SLIDE SPDT 0.4VA 28V
• 1 - CER 10UF 50V X7S RADIAL Capacitor
• 1 - CER 10000PF 400VAC Y5V RAD Capacitor
• 1 - 16 OHM 5% 1/4W AXIAL Resistor
• 1 - Carbon Film 20 Ohm 1/4 Watt 5% Resistor
• 1 - Carbon Film 8.2k Ohm 1/4 Watt 5% Resistor

NI myDAQ student bundle for University of North Dakota students includes:
5 - 100 Ohm  Resistors
5 - 120 Ohm  Resistors
5 - 390 Ohm  Resistors
5 - 500 Ohm  Resistors
2 - 510 Ohm  Resistors
10 - 1k Ohm Resistors
10 - 5k Ohm Resistors
5 - 10k Ohm Resistors
3 - 11k Ohm Resistors
3 - 20k Ohm Resistors
5 - 50k Ohm Resistors
5 - 75k Ohm Resistors
3 - 82k Ohm Resistors
5 - 100k Ohm Resistors
5 - 300k Ohm Resistors
5 - 500k Ohm Resistors
3 - 1M OHM Resistors
3 - 1NA126P op-amp array
10 - 4148 diodes
4 - Zener diodes (3V)
4 - Zener diodes (5V)
6 - ZVN2110A N-channel MOSFETs
2 - 4007 CMOS arrays-dual complimentary pair plus inverter
7 - 3906 transistor arrays
15 - 2N3904 BJTs
9 - 2N3906 BJTs
6 - 741 operational amplifiers
2 - 500k potentiometers/variable resistors
10 - ZVN2106 MOSFETs
8 - through-hole LEDs
1 - 9V battery
