Makeblock Me Compass

Me Slide Potentiometer is one type of potentiometer that can be used to control volume, light intensity, motor speed, movement control, etc. in interactive projects.

Features

• Compatible with the Arduino sensor expansion board;

• Three 4mm mounting holes and one RJ25 port for easy assembling;

• With one red power indicator and one blue potentiometer indicator;

• Anti-reverse connection protection feature.

How Does It Work?

This Me Slide Potentiometer can be combined with Me Orion (or other Arduino IO/sensor expansion board) in interactive projects. Move the lever from one side to the other, its output voltage will range between 0 V to the VCC you apply. The VCC Me Slide Potentiometer supports vary from 3.3V to 5V.


Note

If you connect this module to Me Orion, please make sure you connect it to port 6, port 7 or port 8.

This module is a shield of Arduino UNO. It can turn Arduino pins into Makeblock RJ25 ports. You can connect Arduino UNO with Makeblock electronic modules. This shield provides a stable power, so it can drive many servos and motors.

The Makeblock Me 4 Button can be used in a variety of projects. The Me 4 Button can work as function button or direction button to control your robots. There are 4 momentary buttons on the PCB board which have a great “click” to them. They all share an analog output and different analog values reflect different buttons. You can easily connect it to Me BaseBoard V1.0 or Me BaseShield V2.0 by 6 Pin RJ25 cable.

The Makeblock 57BYG Stepper Motor Bracket can be used as the structural support or connection point for Makeblock 57BYG Stepper Motor.

Makeblock 42BYG geared stepper motor is a simple, but very powerful stepper motor with high output torque and response speed but low noise and energy consumptionhas better performance.

It comes with higher torque than 42BYG stepper motor. It can be used as the power motor of some high-performance machine.

Specification:

• Step Angle (degrees) :1.8
• Phase Current: 2.8A
• Wire Number: 4
• Motor Length: 56mm
• Ratio: 5.18:1
• Output Shaft: D shaft 8mm

This Makeblock Kit contains frequently-used parts in building motion mechanisms.

Part List:

• 4x Link Rod
• 2x Shaft Connector-4
• 2x Timing Pulley18T
• 2x Timing Pulley 66T
• 2x Timing Pulley 90T
• 4x Timing Pulley Slice 90T
• 2x Timing Belt 123T
• 1x Timing Belt 216T
• 4x Threaded Shaft 4x39mm
• 4x Shaft Collar 4mm
• 10x Flange Bearing 4x8x3mm
• 24x Socket Cap Screw M4x14
• 12x Nut M4
• 8x Headless Set Screw M3x5
• 8x Plastic Rivet R4120
• 16x Plastic Ring 4x7x2mm

The Makeblock MG995 Servo Hub is a aluminium high quality part ideal for fitting JR standard, FUTABA standard servos.

Makeblock Beam0808's are frequently used parts within the Makeblock platform to build all kinds of mechanical structures. The Beam0808 series is a reliable structural component, available in varying lengths from 24mm to 504mm.

Makeblock Beam0808's are frequently used parts within the Makeblock platform to build all kinds of mechanical structures. The Beam0808 series is a reliable structural component, available in varying lengths from 24mm to 504mm.

Makeblock Beam0808-072 is one of the most frequently used parts in the Makeblock platform. These beams are essential for the construction of your maker design with a length of 72 mm. They are compatible with most Makeblock motion and structure components.
