Makeblock Me Touch Sensor

The Makeblock Me RGB LED V1 is a shiny Me series module which has 4 full color ws2812 RGB LEDs. It has an integrated chip giving you control of each LED individually to adjust its brightness and create any color by mixing different amounts of red, green, blue.

Me Slide Potentiometer is one type of potentiometer that can be used to control volume, light intensity, motor speed, movement control, etc. in interactive projects.

Features

• Compatible with the Arduino sensor expansion board;

• Three 4mm mounting holes and one RJ25 port for easy assembling;

• With one red power indicator and one blue potentiometer indicator;

• Anti-reverse connection protection feature.

How Does It Work?

This Me Slide Potentiometer can be combined with Me Orion (or other Arduino IO/sensor expansion board) in interactive projects. Move the lever from one side to the other, its output voltage will range between 0 V to the VCC you apply. The VCC Me Slide Potentiometer supports vary from 3.3V to 5V.


Note

If you connect this module to Me Orion, please make sure you connect it to port 6, port 7 or port 8.

The Makeblock Me 4 Button can be used in a variety of projects. The Me 4 Button can work as function button or direction button to control your robots. There are 4 momentary buttons on the PCB board which have a great “click” to them. They all share an analog output and different analog values reflect different buttons. You can easily connect it to Me BaseBoard V1.0 or Me BaseShield V2.0 by 6 Pin RJ25 cable.

The Makeblock Me Infrared Receiver Decode module is designed for receiving infrared signals and controlling the robotics from the infrared remote control. The Infrared Receiver Decode can receive signals well within 10 meters. It may be unable to obtain signal from further than 10 meters. The Makeblock Me Infrared Receiver Decode is simple to wire, easy to program, the controller is compatible with Arduino.

The Makeblock Me Compass is a 3-axis digital compass. The main chip is Honeywell HMC5883L. On-board regulator provides stable power for HMC5883L.

This module is a shield of Arduino UNO. It can turn Arduino pins into Makeblock RJ25 ports. You can connect Arduino UNO with Makeblock electronic modules. This shield provides a stable power, so it can drive many servos and motors.

Standard USB 2.0 cable. Use it to connect Arduino Uno, Arduino Mega 2560, or any board with the USB female A port of your computer. Cable length is approximately 178cm.

The Makeblock 42BYG Stepper Motor Bracket B has the same function as 42BYG Stepper Motor Bracket. It comes with a width of 40mm to adapt to your DIY project.
