Makeblock MEDS15 Servo Motor Bracket - Blue - Pair

This Makeblock Kit contains frequently-used parts in building motion mechanisms.

Part List:

• 4x Link Rod
• 2x Shaft Connector-4
• 2x Timing Pulley18T
• 2x Timing Pulley 66T
• 2x Timing Pulley 90T
• 4x Timing Pulley Slice 90T
• 2x Timing Belt 123T
• 1x Timing Belt 216T
• 4x Threaded Shaft 4x39mm
• 4x Shaft Collar 4mm
• 10x Flange Bearing 4x8x3mm
• 24x Socket Cap Screw M4x14
• 12x Nut M4
• 8x Headless Set Screw M3x5
• 8x Plastic Rivet R4120
• 16x Plastic Ring 4x7x2mm

Makeblock 42BYG geared stepper motor is a simple, but very powerful stepper motor with high output torque and response speed but low noise and energy consumptionhas better performance.

It comes with higher torque than 42BYG stepper motor. It can be used as the power motor of some high-performance machine.

Specification:

• Step Angle (degrees) :1.8
• Phase Current: 2.8A
• Wire Number: 4
• Motor Length: 56mm
• Ratio: 5.18:1
• Output Shaft: D shaft 8mm

Makeblock Butt Hinge (40 X 24mm) is a customized stainless steel butt hinge according to the features of the Makeblock platform.

The Makeblock MG995 Servo Hub is a aluminium high quality part ideal for fitting JR standard, FUTABA standard servos.

• Made from 6061 aluminum extrusion , 8mm thick, anodized surface.
• Compatible with MXL Timing Belt.
• Can also be used as a car wheel.
• Sold in Packs of 4.

The Makeblock 42BYG Stepper Motor Bracket B has the same function as 42BYG Stepper Motor Bracket. It comes with a width of 40mm to adapt to your DIY project.

Makeblock plain ball bearing 8*16*5mm can be used with Makeblock 8mm bearing bracket A to support heavy mechanisms.

Me Slide Potentiometer is one type of potentiometer that can be used to control volume, light intensity, motor speed, movement control, etc. in interactive projects.

Features

• Compatible with the Arduino sensor expansion board;

• Three 4mm mounting holes and one RJ25 port for easy assembling;

• With one red power indicator and one blue potentiometer indicator;

• Anti-reverse connection protection feature.

How Does It Work?

This Me Slide Potentiometer can be combined with Me Orion (or other Arduino IO/sensor expansion board) in interactive projects. Move the lever from one side to the other, its output voltage will range between 0 V to the VCC you apply. The VCC Me Slide Potentiometer supports vary from 3.3V to 5V.


Note

If you connect this module to Me Orion, please make sure you connect it to port 6, port 7 or port 8.

Gear 16T is designed for transmitting motion from a motor to another gear or shaft.  You can use a headless screw M3x5 to attach it.

The Makeblock U Bracket B is usually used as the structural support or connection point for shafts, timing pulley 18T, timing pulley 62T, timing pulley 90T and so on. It has seven 8mm center holes that can be attached with 8mm shaft or bearings.
